The Quilter Labs Bass Block V803 is a powerful and versatile bass amplifier that combines modern Class-D amplification with the warmth of vintage tube sounds. A robust 800W output ensures exceptional performance across various speaker setups, supported by a quiet, variable-speed fan for reliable, heavy-duty use.
| Product Name | Quilter Amps Bass Block V803 800 Watt 1-Channel Vintage Bass Amp |
|---|---|
| Brand | Quilter Amps |
| MPN | BASSBLOCKV803 |
| UPC | 854710003031 |
| Shipping Option | Free Shipping to the Continental U.S. |
- TWO INPUT JACKS: 1meg, Flat and Scoop, 4V peak
- INPUT SWITCH: Mute, Active, Passive
- GAIN
- AMP VOICE SWITCH: Modern, Warm & Q-Tube profiles
- 4-KNOB EQ: Bass +/- 15dB at 100Hz, Mid +/- 15dB with 250-1K Freq Sweep. Treble +/-15dB at 1kHz.
- EFFECTS LOOP: Buffered, 1K Send, 47K Return, 1V peak signal level
- XLR LINE OUT: 1.4V (+4dBu), 600 ohms balanced
- XLR GROUND LIFT: Ground, Lift Auto
- OUTPUT POWER: Up to 450W at 8 ohms, 800 watts at 4 ohms, 25Hz-15kHz
| Input (Flat or Scoop) | ¼" mono, 2M, 4Vpk Passive, 12Vpk Active |
| FX Loop | ¼" mono,1V full scale, 1K out, 47K Input (with FX Send lifted) |
| XLR Out (pre Master) | Balanced, 600 ohms, -6db. Ground lift switch. |
| AC Power Req. | 100–240Vac, 50–60 Hz, 500 W average, 1500W peak |
| Power Output - MODERN | 250W - 16 ohm, 450W - 8 ohm, 800W - 4 ohm |
| Power Output - WARM, QTUBE | 250W - 16 ohm, 450W - 8 ohm, 500W - 4 ohm |
| Headphone (post Master) | ¼" TRS, 39 ohms each side |
| Speaker Output | 4-8 ohms, 90V, 25A peak |
| H x W x D | 3.125" H x 8.5" W" x 7.75" D (7.9375cm x 21.59cm x 19.68cm) |
| Weight | 3.78 lbs (1.715 kg) |
Quilter Amps Bass Block V803 800 Watt 1-Channel Vintage Bass Amp
Details
The Quilter Labs Bass Block V803 is a powerful and versatile bass amplifier that combines modern Class-D amplification with the warmth of vintage tube sounds. A robust 800W output ensures exceptional performance across various speaker setups, supported by a quiet, variable-speed fan for reliable, heavy-duty use.
| Product Name | Quilter Amps Bass Block V803 800 Watt 1-Channel Vintage Bass Amp |
|---|---|
| Brand | Quilter Amps |
| MPN | BASSBLOCKV803 |
| UPC | 854710003031 |
| Shipping Option | Free Shipping to the Continental U.S. |
Features
- TWO INPUT JACKS: 1meg, Flat and Scoop, 4V peak
- INPUT SWITCH: Mute, Active, Passive
- GAIN
- AMP VOICE SWITCH: Modern, Warm & Q-Tube profiles
- 4-KNOB EQ: Bass +/- 15dB at 100Hz, Mid +/- 15dB with 250-1K Freq Sweep. Treble +/-15dB at 1kHz.
- EFFECTS LOOP: Buffered, 1K Send, 47K Return, 1V peak signal level
- XLR LINE OUT: 1.4V (+4dBu), 600 ohms balanced
- XLR GROUND LIFT: Ground, Lift Auto
- OUTPUT POWER: Up to 450W at 8 ohms, 800 watts at 4 ohms, 25Hz-15kHz
Tech Specs
| Input (Flat or Scoop) | ¼" mono, 2M, 4Vpk Passive, 12Vpk Active |
| FX Loop | ¼" mono,1V full scale, 1K out, 47K Input (with FX Send lifted) |
| XLR Out (pre Master) | Balanced, 600 ohms, -6db. Ground lift switch. |
| AC Power Req. | 100–240Vac, 50–60 Hz, 500 W average, 1500W peak |
| Power Output - MODERN | 250W - 16 ohm, 450W - 8 ohm, 800W - 4 ohm |
| Power Output - WARM, QTUBE | 250W - 16 ohm, 450W - 8 ohm, 500W - 4 ohm |
| Headphone (post Master) | ¼" TRS, 39 ohms each side |
| Speaker Output | 4-8 ohms, 90V, 25A peak |
| H x W x D | 3.125" H x 8.5" W" x 7.75" D (7.9375cm x 21.59cm x 19.68cm) |
| Weight | 3.78 lbs (1.715 kg) |
