The GRID SLAMMER™ Overdrive is an overdrive pedal that produces a variable boost in gain over a wide range with a classic, guitar-centric midrange bump that enhances many different playing styles. It’s a true overdrive “specialist” that covers an amazing array of what many top players consider the most expressive and musical ranges of overdrive. From sweet, subtle breakup to a harmonically smoldering overdrive that can both sting and sing, the GRID SLAMMER sets a new bar in legendary overdrive!
Check out some sweet Tele tones with the Mesa Boogie Grid Slammer Overdrive!
{{asset=616,align=center,width=75%}}
Some Blues Rhythm tones!
{{asset=617,align=center,width=75%}}
Walter Trout shows off some solo Blues licks with the Grid Slammer!
{{asset=618,align=center,width=75%}}
Mesa/Boogie products are ONLY available for US shipping, must be a US resident.
Shipping charges apply – Please see shipping calculator for quote.
| Product Name | Mesa Boogie Grid Slammer Drive Guitar Pedal |
|---|---|
| Brand | Mesa Boogie |
| Condition | New |
| MPN | FPGRIDSLAMMER |
| UPC | 809404115170 |
| Shipping Option | This product does not qualify for free shipping |
- Designed and Hand-Built in Petaluma, California, USA
- True Bypass On/Off Switching - Bypasses all circuitry when off to ensure no tonal loss
- Gain Control allows you to dial in the perfect amount of vintage breakup or classic overdrive
- Master Level Control provides a variable range of signal boost up to +20db
- Tone Control balances the amount of high frequencies
- On/Off Status LED
- 9V Battery Powered or optional AC Powered via External Power Jack Input
- Input & Output Jacks (Nominal Input -20 db)
Specs:
- Dimensions (W/D/H): 2.87" x 4.77" x 2.28" (73mm x 122mm x 58mm)
- Weight: 0.731 lbs. (332g) with battery, 0.631 lbs. (287g) without battery
- True Bypass Switching
- Battery Type: 9VDC (one)
- Power Consumption (Current Draw): 9VDC/15mA
- External Power Supply (Not Included): WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with a NEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.
- Input Impedance: 1M Ohm (500k Ohm minimum)
- Output Impedance: 10k Ohm
Mesa Boogie Grid Slammer Drive Guitar Pedal
The GRID SLAMMER™ Overdrive is an overdrive pedal that produces a variable boost in gain over a wide range with a classic, guitar-centric midrange bump that enhances many different playing styles. It’s a true overdrive “specialist” that covers an amazing array of what many top players consider the most expressive and musical ranges of overdrive. From sweet, subtle breakup to a harmonically smoldering overdrive that can both sting and sing, the GRID SLAMMER sets a new bar in legendary overdrive!
Check out some sweet Tele tones with the Mesa Boogie Grid Slammer Overdrive!
{{asset=616,align=center,width=75%}}
Some Blues Rhythm tones!
{{asset=617,align=center,width=75%}}
Walter Trout shows off some solo Blues licks with the Grid Slammer!
{{asset=618,align=center,width=75%}}
Mesa/Boogie products are ONLY available for US shipping, must be a US resident.
Shipping charges apply – Please see shipping calculator for quote.
| Product Name | Mesa Boogie Grid Slammer Drive Guitar Pedal |
|---|---|
| Brand | Mesa Boogie |
| Condition | New |
| MPN | FPGRIDSLAMMER |
| UPC | 809404115170 |
| Shipping Option | This product does not qualify for free shipping |
- Designed and Hand-Built in Petaluma, California, USA
- True Bypass On/Off Switching - Bypasses all circuitry when off to ensure no tonal loss
- Gain Control allows you to dial in the perfect amount of vintage breakup or classic overdrive
- Master Level Control provides a variable range of signal boost up to +20db
- Tone Control balances the amount of high frequencies
- On/Off Status LED
- 9V Battery Powered or optional AC Powered via External Power Jack Input
- Input & Output Jacks (Nominal Input -20 db)
Specs:
- Dimensions (W/D/H): 2.87" x 4.77" x 2.28" (73mm x 122mm x 58mm)
- Weight: 0.731 lbs. (332g) with battery, 0.631 lbs. (287g) without battery
- True Bypass Switching
- Battery Type: 9VDC (one)
- Power Consumption (Current Draw): 9VDC/15mA
- External Power Supply (Not Included): WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with a NEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.
- Input Impedance: 1M Ohm (500k Ohm minimum)
- Output Impedance: 10k Ohm
