Heritage Audio OST10 V1 10 Slot Rack with OS Tech

Heritage Audio OST10 V1 10 Slot Rack with OS Tech

On order with the manufacturer!

The new Heritage OST-10 is a handy 500 series enclosure utilizing a 3U rack format that allows for the use of up to 10 modules at one time. Featuring ON SLOT technology, each module has its own power supply regulation and is isolated from the rest and overall power capability is heightened greatly.
View full details
  • Details
  • Features
  • Reviews

Heritage Audio OST10 10 Slot Rack with OS Tech:

The OST-10 is a 500 Series enclosure in a 3U Rack format, able to accommodate up to 10 modules. As the rest of the new Heritage Audio line of 500 Series enclosures, it features "ON SLOT" Technology (OTS).

"ON SLOT TECHNOLOGY" takes advantage of last generation power electronics to handle power supply on a "per slot" basis. Each slot has its own power supply linear regulation stages, therefore modules are isolated from the rest. They just share the metal enclosure.

With literally hundreds of brands making 500 series modules, we at Heritage Audio think this is the professional way of handling this reliably, eliminating issues often associated with sharing power between different modules of different brands and natures.

Each slot features test leds for checking correct power operation (red for +16v, green for -16v), located aside of the slot connector.

Thanks to the use of OST, the power capability of the OST-10 is 400mA per rail per slot maximum, with an overall of 1.6A (1.8A non continuous) per rail, whichever is reached first. Each slot has its own red (+16v) and green (-16v) leds for easy testing of the power status.

The RAF Blue Gray enclosure is made out of heavy gauge steel with an aluminum front panel in the United Kingdom.

Phantom power available is 140mA total.

More Information
Product Name Heritage Audio OST10 V1 10 Slot Rack with OS Tech
Brand Heritage Audio
Condition New
MPN HAOST10
UPC 702877907177
Shipping Option Free Shipping to the Continental U.S.
  • 500 Series enclosure in a 3U Rack format with room for up to 10 modules
  • Features “On Slot” technology that grants each slot its own power supply linear regulation stages, isolating individual modules from the rest
  • Each slot features test LEDs for checking correct power operation
  • power capability of  400mA per rail per slot maximum, with an overall of 1.6A (1.8A noncontinuous) per rail, whichever is reached first
  • Each slot has its own red (+16v) and green (-16v) LEDs for easy testing of the power status
  • RAF Blue Gray enclosure is made out of heavy gauge steel with an aluminum front panel

Heritage Audio OST10 V1 10 Slot Rack with OS Tech

Details

Heritage Audio OST10 10 Slot Rack with OS Tech:

The OST-10 is a 500 Series enclosure in a 3U Rack format, able to accommodate up to 10 modules. As the rest of the new Heritage Audio line of 500 Series enclosures, it features "ON SLOT" Technology (OTS).

"ON SLOT TECHNOLOGY" takes advantage of last generation power electronics to handle power supply on a "per slot" basis. Each slot has its own power supply linear regulation stages, therefore modules are isolated from the rest. They just share the metal enclosure.

With literally hundreds of brands making 500 series modules, we at Heritage Audio think this is the professional way of handling this reliably, eliminating issues often associated with sharing power between different modules of different brands and natures.

Each slot features test leds for checking correct power operation (red for +16v, green for -16v), located aside of the slot connector.

Thanks to the use of OST, the power capability of the OST-10 is 400mA per rail per slot maximum, with an overall of 1.6A (1.8A non continuous) per rail, whichever is reached first. Each slot has its own red (+16v) and green (-16v) leds for easy testing of the power status.

The RAF Blue Gray enclosure is made out of heavy gauge steel with an aluminum front panel in the United Kingdom.

Phantom power available is 140mA total.

More Information
Product Name Heritage Audio OST10 V1 10 Slot Rack with OS Tech
Brand Heritage Audio
Condition New
MPN HAOST10
UPC 702877907177
Shipping Option Free Shipping to the Continental U.S.
Features
  • 500 Series enclosure in a 3U Rack format with room for up to 10 modules
  • Features “On Slot” technology that grants each slot its own power supply linear regulation stages, isolating individual modules from the rest
  • Each slot features test LEDs for checking correct power operation
  • power capability of  400mA per rail per slot maximum, with an overall of 1.6A (1.8A noncontinuous) per rail, whichever is reached first
  • Each slot has its own red (+16v) and green (-16v) LEDs for easy testing of the power status
  • RAF Blue Gray enclosure is made out of heavy gauge steel with an aluminum front panel
